HPM Vivo 10A 1 Gang Vertical Rocker Switch Plate White

Vivo HPM

HPM Vivo 10A 1 Gang Vertical Rocker Switch Plate White

REF. EV770/1WE Barcode. 9321001465461
1 Year Warranty
Download product sheet
You can compare up to 4 products
Features
  • 1 Gang
  • 10AX 2 way single Pole Double Throw
  • Sleek & Square design
  • Includes common coverplate that is interchangable with the 14 colour finishes of the Vivo range
User Recommendations
  • Suitable for all commercial and residential installations such as kitchens, bedrooms, offices, retail, hospitality and education facilities
  • Cut-out size: 56 x 96mm
Overview
The HPM Vivo 10A Vertical Rocker Switch Plate is a sleek and practical solution for controlling lighting in your home. Its sleek, square design complements any decor, while the interchangeable cover plate allows for customisation to suit your style. With easy installation and a user-friendly design, this switch plate offers an attractive and functional way to manage lighting.

Quality You Can Trust

Installation
  • Oval 84mm fixing points - making it easier to adjust when installing
Unique Characteristics
  • Customise to suit your tastes and your interior with the coloured coverplate options (sold separately)

Technical Specifications

Method of operation Rocker/button
Push button switch No
Number of rockers 1
Mounting method Surface mounted
Type of fastening Screw mounting
With mounting plate Yes , Yes
Material Plastic
Surface finishing Glossy
Colour White
Colour of switch operator White
Nominal voltage 240 V
Rated current 10 A
Device width 85 mm
Device height 119 mm
Device depth 10 mm

Documentation

1 document
Technical Sheet
